H05VV5-F Copper Core PVC Insulated PVC Sheathed Flexible Cable

    H05VV5-F Copper Core PVC Insulated PVC Sheathed Flexible Cable

    Our Copper Core PVC Insulated PVC Sheathed Flexible Cable is engineered for superior reliability, flexibility, and safety in electrical installations. Featuring pure copper conductors, it delivers excellent conductivity and efficient power transmission. The dual PVC insulation and sheath provide robust protection against heat, moisture, chemicals, and mechanical wear, ensuring long-lasting performance in residential, commercial, and industrial environments. Ideal for wiring, power distribution, and flexible installations, this cable combines durability, safety, and high performance, making it...
  • Share：
    • Contact us Inquiry
  • E-mail：470647052@qq.com
    WhatsApp：+86 13391229506

H05VV5-F 300/500V


Copper Core PVC Insulated PVC Sheathed Flexible Cable


Applications

These cables are suitable for use in dry, humid environments, but not in outdoor use. They are used as shielded terminations and connecting lines in control, measurement, and signaling technology. The copper wire braid shields against external interference, such as electromagnetic fields and stray frequencies. They are used as signal and pulse cables in industrial plants, machinery, and process control and inspection systems.


Product Structure

Reference Standard: VDE 0281.13

Conductor: Multiple finely stranded bare copper wires, in accordance with EN 60228, Category 5 conductor

Insulation: Environmentally friendly PVC

Filling (optional): Mesh polypropylene or cotton

Sheath Material: Oil-resistant PVC

Sheath Color: Black and other colors

Wire Color: Color-coded or black with printed numbers


Technical Parameters

Rated Voltage: 300/500V

Test Voltage: 2000V

Rated Temperature: -15°C to +70°C

Minimum Bend Radius:

Fixed Installation: 6 x Cable OD

Mobile Installation: 15 x Cable OD

Environmental Requirements: RoHS and REACH Compliant

Flame Retardant: Complies with IEC 60332-1-2

Outer Sheath Oil Resistance: Complies with IEC 60811-2-1


Product Features

Mechanical Properties: Average

Good Peelability


Product Parameters

Number of cores × cross-sectional area


(n*mm²)

Insulation thickness

(mm)

Sheath thickness  (mm)

Approximate outer diameter of cable

(mm)

Conductor resistance at 20°C.max
(Q/km)
copper coreTinned copper core
2*0.50.6 0.7 5.6 39.0 40.1
2*0.750.6 0.8 6.2 26.0 26.7
2*1.00.6 0.8 6.6 19.5 20.0
2*1.50.7 0.8 7.6 13.3 13.7
2*2.50.8 0.9 9.0 7.98 8.21
3*0.50.6 0.7 6.0 39.0 40.1
3*0.750.6 0.8 6.6 26.0 26.7
3*1.00.6 0.8 7.0 19.5 20.0
3*1.50.7 0.9 8.3 13.3 13.7
3*2.50.8 1.0 9.8 7.98 8.21
4*0.50.6 0.8 6.7 39.0 40.1
4*0.750.6 0.8 7.2 26.0 26.7
4*1.00.6 0.8 7.7 19.5 20.0
4*1.50.7 0.7 8.7 13.3 13.7
4*2.50.8 0.8 10.4 7.98 8.21
5*0.50.6 0.8 7.3 39.0 40.1
5*0.750.6 0.9 8.1 26.0 26.7
5*1.00.6 0.9 8.6 19.5 20.0
5*1.50.7 1.0 10.1 13.3 13.7
5*2.50.8 1.1 12.0 7.98 8.21
6*0.50.6 0.9 8.2 39.0 40.1
6*0.750.6 0.9 8.8 26.0 26.7
6*1.00.6 1.0 9.6 19.5 20.0
6*1.50.7 1.1 11.2 13.3 13.7
6*2.50.8 1.2 13.3 7.98 8.21
7*0.50.6 0.9 8.2 39.0 40.1
7*0.750.6 1.0 9.0 26.0 26.7
7*1.00.6 1.0 9.6 19.5 20.0
7*1.50.7 1.2 11.4 13.3 13.7
7*2.50.8 0.8 12.5 7.98 8.21
12*0.50.6 1.1 11.0 39.0 40.1
12*0.750.6 1.1 11.8 26.0 26.7
12*1.00.6 1.2 12.9 19.5 20.0
12*1.50.7 1.3 15.1 13.3 13.7
12*2.50.8 0.8 16.6 7.98 8.21
18*0.50.6 1.2 13.0 39.0 40.1
18*0.750.6 1.3 14.2 26.0 26.7
18*1.00.6 1.3 15.2 19.5 20.0
18*1.50.7 1.5 18.0 13.3 13.7
18*2.50.8 0.8 19.7 7.98 8.21
